Applications and Features |
|||||||||||||
( 1 ) Suitable for butt or fillet welding of mild steel (thickness < ( 2 ) Excellent mechanical properties, crack resistance and capable of X-ray quality welds. ( 3 ) Stable arc, easy control of weld puddle, low spatters, good penetration, good slag removal and bead appearance. |
|||||||||||||
Welding position |
|||||||||||||
|
|||||||||||||
Welding Instruction |
|||||||||||||
Please refer to Appendix A |
|||||||||||||
Typical Chemical Composition of Weld Metal (wt%) |
|||||||||||||
C |
Si |
Mn |
P |
S |
|||||||||
0.08 |
0.08 |
0.45 |
0.014 |
0.008 |
|||||||||
Typical Mechanical Properties of Weld Metal |
|||||||||||||
Tensile Strength |
Yield Strength |
Elongation |
Charpy V-Notch |
||||||||||
℃ |
J |
||||||||||||
470 |
400 |
28 |
0 |
95 |
|||||||||
-20 |
75 |
||||||||||||
Size and Suggested Operating Range (AC or DC±) |
|||||||||||||
Diameter (mm) |
3.2 |
4.0 |
5.0 |
6.0 |
|||||||||
Current |
F/H-fillet |
80~120 |
120~170 |
170~240 |
230~300 |
||||||||
V-up/OH |
60~110 |
110~160 |
- |
- |
