Welding Instruction |
||||||||||||
|
||||||||||||
Typical Chemical Composition of Weld Metal (wt %) |
||||||||||||
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Nb |
Fe |
Mo |
|||
0.080 |
0.40 |
1.90 |
0.009 |
0.008 |
68.00 |
14.20 |
1.76 |
9.20 |
2.40 |
|||
Typical Mechanical Properties of Weld Metal |
||||||||||||
Tensile Strength N/mm2(kgf/mm2) |
Yield Strength N/mm2(kgf/mm2) |
Elongation % |
Charpy V-Notch |
|||||||||
°C |
J(Kgf-m) |
|||||||||||
600(61.2) |
390(39.8) |
43 |
-196 |
72(4.1) |
||||||||
Size and Suggested Operating Range (DC+) |
||||||||||||
Diameter (mm) x Length(mm) |
2.6x300 |
3.2x350 |
4.0x350 |
4.8x350 |
||||||||
Amp |
H |
60~85 |
80~120 |
100~150 |
140~180 |
|||||||
V/O-H |
55~85 |
65~110 |
85~135 |
— |
