Welding Instruction |
|||||||||||||||||
|
|||||||||||||||||
Typical Chemical Composition of Weld Metal (wt %) |
|||||||||||||||||
C |
Si |
Mn |
P |
S |
Ni |
Fe |
Cu |
Ti |
|||||||||
0.060 |
0.90 |
0.60 |
0.007 |
0.009 |
96.53 |
0.40 |
0.10 |
2.00 |
|||||||||
Typical Mechanical Properties of Weld Metal |
|||||||||||||||||
Tensile Strength N/mm2(kgf/mm2) |
Yield Strength N/mm2(kgf/mm2) |
Elongation % |
Charpy V-Notch |
||||||||||||||
°C |
J(Kgf-m) |
||||||||||||||||
520(53.0) |
305(31.1) |
42 |
20 |
120(12.2) |
|||||||||||||
Size and Suggested Operating Range (DC+) |
|||||||||||||||||
Diameter (mm) x Length(mm) |
2.6x300 |
3.2x350 |
4.0x350 |
4.8x350 |
|||||||||||||
Amp |
H |
60~85 |
80~120 |
100~150 |
140~180 |
||||||||||||
V/O-H |
55~85 |
65~110 |
85~135 |
— |
