| Product name：KCH-13MC-O |
| Classification：- |
  |
- KCH-13MC-0 is a self-shielded flux cored wire of Cr-Mn alloy.
- It is used as a buffer layer before hardfacing. Weld metal can be machined and cut.
- It is suitable for the buffer layer of coal pulverizer and repairing the worn work piece which is caused by heavy impact and wear.
|
Welding Instruction |
||||||
|
(1) Dry the surface of work piece to prevent the porosity caused by moisture. (2) For high carbon steel or alloy steel, preheat and interpass temperature should be 150~250°C to prevent cracks. |
||||||
|
Typical Chemical Composition of Weld Metal (wt. %) |
||||||
|
C |
Si |
Mn |
Cr |
|||
|
0.50 |
0.50 |
11.50 |
18.00 |
|||
|
Typical Hardness of Weld Metal |
||||||
|
|
1st layer |
2nd layer |
3rd layer |
|||
|
Hardness（HRC） |
21~24 |
22~26 |
25~28 |
|||
|
Size and Suggested Operating Range (DC+) |
||||||
|
Size (mm) |
Voltage （V） |
Current（A） |
ESO（mm） |
|||
|
2.4 |
26~30 |
200~340 |
50~60 |
|||
|
2.8 |
28~32 |
250~400 |
50~70 |
|||
