Applications and Features |
|||||||||||||
(1) Suitable for welding 490N/mm2 grade steel. (2) Good arc starting and re-start, stable arc, low spatters, good slag removal and good bead appearance. (3) Applicable for welding on automobiles steel plate, sheet metal, light structure steel and underwater welding. Ideal for welding thin sheet due to the less penetration. |
|||||||||||||
Welding position |
|||||||||||||
|
|||||||||||||
Welding Instruction |
|||||||||||||
Please refer to Appendix A. |
|||||||||||||
Typical Chemical Composition of Weld Metal (wt%) |
|||||||||||||
C |
Si |
Mn |
P |
S |
|||||||||
0.08 |
0.31 |
0.52 |
0.019 |
0.007 |
|||||||||
Typical Mechanical Properties of Weld Metal |
|||||||||||||
Tensile Strength N/mm2 |
Yield Strength N/mm2 |
Elongation % |
Charpy V-Notch |
||||||||||
℃ |
J |
||||||||||||
536 |
462 |
22 |
0 |
70 |
|||||||||
Size and Suggested Operating Range (AC or DC±) |
|||||||||||||
Diameter (mm) |
3.2 |
4.0 |
5.0 |
6.0 |
|||||||||
Current (A) |
F/H-Fillet |
90~130 |
130~180 |
180~240 |
230~300 |
||||||||
V-up/OH |
90~110 |
130~160 |
- |
- |
