Applications and Features |
|||||||||||||
(1) Suitable for welding 490N/mm2 grade steel, low alloy steel, medium-carbon steel, heavy steel plates and cast steels. (2) Stable arc, easy control of weld puddle, low spatters, good slag removal and bead appearance, good penetration and X-ray quality. (3) Applicable for base metal of structural steel, steel tubes for heat exchanger, plate for pressure vessel, low-alloy steel tube and mechanical structural carbon-steel plate. |
|||||||||||||
Welding position |
|||||||||||||
|
|||||||||||||
Welding Instruction |
|||||||||||||
Please refer to Appendix A. |
|||||||||||||
Typical Chemical Composition of Weld Metal (wt%) |
|||||||||||||
C |
Si |
Mn |
P |
S |
|||||||||
0.08 |
0.53 |
1.02 |
0.012 |
0.008 |
|||||||||
Typical Mechanical Properties of Weld Metal |
|||||||||||||
Tensile Strength N/mm2 |
Yield Strength N/mm2 |
Elongation % |
Charpy V-Notch |
||||||||||
℃ |
J |
||||||||||||
568 |
468 |
29 |
0 |
211 |
|||||||||
-29 |
152 |
||||||||||||
Size and Suggested Operating Range (AC or DC+) |
|||||||||||||
Diameter (mm) |
3.2 |
4.0 |
5.0 |
6.0 |
|||||||||
Current (A) |
F/HF |
90~130 |
130~180 |
180~240 |
230~300 |
||||||||
V-up/OH |
80~120 |
110~160 |
150~200 |
- |
